Clamp Ø 19 mm aluminium – Group 3

This robust aluminium tube clamp from AEGI is used for securely mounting pipes, tubes, or hoses. Within the mobility and assistive technology sector, these clamps are ideal for custom modifications, such as frame adjustments, or other special constructions.

The clamp belongs to Group 3 and corresponds to the standard series according to DIN 3015-1. The LA3 19 series consists of two aluminium halves with a profiled inner surface for enhanced grip and vibration damping. Thanks to its rigid metal design, this version offers excellent dimensional stability even under load or temperature changes.

The clamp is mounted with two M6 bolts, with a bolt spacing of 33 mm, making it easy to install on flat surfaces or mounting plates.

We supply this clamp per piece (2 halves) instead of industrial packs of 25 — ideal for prototypes, custom builds, or small repairs.

Features:
– Inner Ø 19 mm
– Group 3 (DIN 3015-1 Standard Series)
– Series LA3 19
– Aluminium body
– Profiled inner surface for improved grip
– Mounting with 2 × M6 bolts (spacing 33 mm)
– High stiffness, suitable for heavy-duty applications
– Fixed mounting (non-sliding)
– Weight ≈ 0.08 kg
– Supplied per piece (2 halves)

Suitable for various technical and rehabilitation applications, such as mounting on wheelchairs, scooters, bicycles, and other assistive devices where strength and secure attachment are required.
